Dublin Core
Title
Photo of a Digital KDF-11B CPU Board
Description
A photograph of the KDF-11B is a CPU processor module developed by Digital Equipment Corporation (DEC) for its PDP-11 family of 16-bit minicomputers. The KDF-11B board is associated with the PDP-11/23+.
Technically, the KDF-11B is a quad-height CPU module that encapsulates the core PDP-11 instruction set and execution logic using DEC’s F-11 chipset. In addition to the core processor functions, the board included sockets for optional features such as memory management units and floating-point units, onboard ROM for bootstrap and diagnostics, and integrated serial communication interfaces.
Technically, the KDF-11B is a quad-height CPU module that encapsulates the core PDP-11 instruction set and execution logic using DEC’s F-11 chipset. In addition to the core processor functions, the board included sockets for optional features such as memory management units and floating-point units, onboard ROM for bootstrap and diagnostics, and integrated serial communication interfaces.
Creator
Digital Equipment Corporation
Date
ca 1981
Contributor
Charles Valentine
Identifier
2026.69
Still Image Item Type Metadata
Physical Dimensions
8x10 Photographic Print
